5 Mil 8mm Polished Stainless Steel Plate Sheets 201 202 304 316 310S 309S 430 2205 9 Gauge
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | JIANGSU ZHIJIA STEEL |
| Model Number | Tisco - 01 |
| Minimum Order Quantity | Negotiation |
| Price | Negotiation |
| Packaging Details | Waterproof Paper+Metal Band Strapping+Protective Steel Ring+Fumigation Wooden Frame |
| Supply Ability | 2000 Ton/Tons per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Delivery Time | 7-15 Days | Type | 5 Mil 8mm Polished Stainless Steel Sheet Metal 201 202 304 316 310S 309S 430 2205 9 Gauge Plate |
|---|---|---|---|
| Length | 2000/2438/2500/3000/3048 Mm | Grade | 300 Series |
| Standard | JIS ASTM AISI EN DIN GB | Thickness | 0.1-3mm, 3-100mm |
| Width | 1000/1219/1250/1500 Mm | Application | Decoration And Fabrication |
| Tolerance | ±3% | Processing Service | Bending, Welding, Decoiling, Punching, Cutting |
| Steel Grade | 301, 310S, 316L, 441, 316, 430, 309S, 304, 304L, 904L, 201, 202 | Surface Finish | 2B |
| Product Name | 304 Stainless Steel Sheet | Surface | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
| Edge | Mill Edge &Slit Edge | Packing | PVC+waterproof Paper+wooden Case |
| Technique | Cold Rolled Hot Rolled | Sample | Freely |
| Port | Shanghai | ||
| High Light | 5 mil stainless steel sheet,8mm stainless steel sheet,9 gauge stainless steel sheet |
||
Product Description
5 Mil 8mm Polished Stainless Steel Sheet Metal 201 202 304 316 310S 309S 430 2205 9 Gauge
| Surface Finish | Definition | Application | |
| 2B | Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface. | With bright and smooth surface ,easy for further grinding to obtain brighter surface ,suitable for medical instruments ,milk containers ,tableware and so on. | |
| BA | Bright heat treatment after cold rolling. | Structual members .etc.kitchen utensil ,cutlery ,eleltric applicances ,medical instruments ,building decorations ,etc. | |
| NO.3/NO.4 | Polished with No.150-240 abrasives. | Milky food processing equipment , medicalinstruments ,building decorations. | |
| HL | Finshed by polishing with abrasives of suitable grain size to obtain continuous streaks. | Building decorations ,such as elevators ,escalators ,door etc. | |
| 6K/8K | A mirror-like reflective surface ,which is obtained by polishing with successively finer abrasives and buffing extensively with all gritlines are removed. | Buliding entrances,bulkding column casting ,elevator's wall doors ,counters,sculptures etc. | |
| Stainless Steel Coil/Sheet/Plate Information | |||||||||||
| Technique | Surface Finish | Grade Series | Thickness(mm) | Width(mm) | Application | ||||||
| Main Dimension | |||||||||||
| 20-850 | 1000 | 1219 | 1240 | 1250 | 1500 | Petro-chemical industry,Tanks Construction material | |||||
| Hot Rolled | No.1 / 2E | 201/202/ 304 | 2.2-12.0 | √ | √ | √ | √ | √ | |||
| Cold Rolled | 2B | 201/304 | 0.25-3.0 | √ | √ | √ | √ | √ | √ | ||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | ||||||
| No.4 / Hairline Mirror / Linen SB | 201/304 | 0.22-3.0 | √ | √ | √ | √ | √ | ||||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | √ | |||||
| BA | 201/304 | 0.2--1.8 | √ | √ | √ | √ | |||||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | ||||||
| 2BA | √ | √ | √ | √ | |||||||
| Chemical composition and mechanical properties of stainless steel coils | |||||||||
| Grade | Chemical Composition (%) | Mechanieal Performece | |||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Hardness | |
| 201 | ≤0.15 | ≤1.00 | 5.5/7.5 | ≤0.060 | ≤0.030 | 3.5/5.5 | 16.0/18.0 | - | HB≤241,HRB≤100, HV≤240 |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.0/11.0 | 18.00/20.00 | - | HB≤187,HRB≤90,HV≤200 |
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00/14.00 | 16.0/18.0 | 2.00/3.00 | HB≤187, HRB≤90 HV≤200 |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00/14.00 | 16.0/18.0 | 2.00/3.00 | HB≤187, HRB≤90 HV≤200 |
| 410 | ≤0.15 | ≤1.00 | ≤1.25 | ≤0.060 | ≤0.030 | ≤0.060 | 11.5/13.5 | - | HB≤183, HRB≤88 HV≤200 |
| 430 | ≤0.12 | ≤1.00 | ≤1.25 | ≤0.040 | ≤0.03 | - | 16.00/18.00 | - | HB≤183, HRB≤88 HV≤200 |
Company Profile
Jiangsu Chunyi Stainless Steel Co., Ltd. is a large-scale Wuxi stainless steel industry and trade enterprise integrating stainless steel plate wholesale and processing, warehousing and distribution. The company is located in Wuxi, the distribution center of stainless steel trading. It is a stainless steel plate supplier integrating stainless steel coil material, stainless steel plate sales, processing and distribution, and after-sales technical consulting services.
The company's products cover a variety of Wuxi stainless steel plate series of materials, standing stock.
1. 2B board SUS316L, 310S, 304, 202, 201, 430, 420 and other oily sand, finely ground 8K mirror panel, titanium plate, deep drawing board, drawing board, and frosted board.
2. Industrial plate/2B SUS316L, 321, 304, 310S acid and alkali resistant, high temperature resistant sheet, pipe, round steel, channel steel, angle steel, flat steel, etc.
3. Various materials of calendering belt, punching plate, anti-skid plate, and undertaking deep processing such as shearing and pressing.
Jiangsu Chunyi Stainless Steel Co., Ltd. has always implemented the business philosophy and service tenet of "high-speed, high-efficiency, pragmatic development, customer-oriented, service first". With the care and support of colleagues and customers from all walks of life, we have continued to develop steadily, and our products have been exported to all parts of the country. The company will serve customers with high-quality products, good reputation and low prices. I would like to express my heartfelt gratitude to the old and new customers who have given us the care and support of our company! And sincerely hope to establish a long-term cooperative relationship with them for mutual benefit and common development!
