310S 309S Equal Angle Bar 300 Series Laser Welded Stainless Steel Profiles Wall Paneling

Quality Guarantee Cold Rolled 304 321 310S Stainless Steel Angle Equal Bar 309s

Product Description

Cold Rolled 304 321 310S Stainless Steel Angle Equal Bar 309s

"Quality is our culture."
Welcome know more about our company.
1.15+rich experiece in stainless steel sheet,coil and all kinds of bars;
2.The company was awarded the gold product by Ali and vertified by sgs certification;
3.Competive prices with cusomer oriednted
4.Exported to more than 100 countries;
5.Fast delivery in 5 days
Any questions, pls feel free to let me know and I will reply you in 2 hours;
Looking forward to your reply!

ITEM	Stainless Steel Bars/Channel/Angle/Round Bar/Hexagonal Bar
Size	Thickness:3-24mm; Length:3m,6m,9m,12m, or customized
Tolerance	Weight tolarance: -4% TO -10%;Width +/-0.8mm;Thickness +/-0.4mm;Length:4-12mm
Brand	RONSCO,BAOSTEEL, JISCO, TISCO, etc.
Equal Angle	Type: 2#-20#;Size: 20-200mm;Thickness: 3.0-24mm; Weight: 0.597-71.168kg/m
Unequal Angle	Type: 2.5*1.6-20*12.5#;Size:25*16-200*125mm;Long Side: 25-200mm Short Side: 16-125mm;Thickness: 3.0-18mm;Weight: 1.687-43.588kg/m
Material	201.202.301.302.304.304L.310S.316.316L.321.347,329,309S.2205.2507.2520. 430.410.440.904Lect. Or Customized
Standard	GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Surface	Mill finish. Galvanized.Forged.Hot Rolled.Cold Drawn.Peeled or customized
Trade Term	FOB CIF CFR CNF EXWORK
Application	widely used in a variety of architectural and enginee ring structures,such as a.) beams, bridges, ship; b.) transmission tower, reaction tower; c.) lifting transportation machinery; d.) industrial furnace; e.)container frame, warehouse goods shelves, etc
Package	Standard export sea-worthy packing or customized
Lead Time	3-15 days after deposit
Payment	TT/LC
Sample	we could offer the sample for free charge but do not pay the cost of freight.

Chemical Component

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0.15	≤0.75	5.5-7.5	≤0.06	≤0.03	3.5-5.5	16.0-18.0	-
202	≤0.15	≤1.0	7.5-10.0	≤0.06	≤0.03	4.-6.0	17.0-19.0	-
301	≤0.15	≤1.0	≤2.0	≤0.045	≤0.03	6.0-8.0	16.0-18.0	-
302	≤0.15	≤1.0	≤2.0	≤0.035	≤0.03	8.0-10.0	17.0-19.0	-
304	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	8.0-10.5	18.0-20.0
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤0.03	9.0-13.0	18.0-20.0
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	12.0-15.0	22.0-24.0
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤0.03	19.0-22.0	24.0-26.0
316	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.0	≤2.0	≤0.045	≤0.03	12.0-15.0	16.0-18.0	2.0-3.0
321	≤0.08	≤1.0	≤2.0	≤0.035	≤0.03	9.0-13.0	17.0-19.0	-
904L	≤2.0	≤0.045	≤1.0	≤0.035	-	23.0-28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.80	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤0.03	0.19-0.22	0.24-0.26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤0.03	-	11.5-13.5	-
430	0.12	≤0.75	≤1.0	≤0.040	≤0.03	≤0.60	16.0-18.0	-

HOT ROLLED EQUAL STEEL ANGLE HXBXT(mm)				HOT ROLLED EQUAL STEEL ANGLE HXBXT(mm)
20X20X3/4	80X80X5/6/7/8/9/10		25x16/3/4	110X70X6/7/8/10
25X25X3/4	90X90X6/7/8/9/10/12		32x20x3/4	125X80/7/8/10/12
30X30X3/4	100X100X6/7/8/9/10/12/14/16		40X25X3/4	140X90X8/10/12/14
36X36X4/5	110X110X7/8/9/10/12/14		45X45X3/4	160X110X10/12/14/16
12540X40X4/5/6	125X125X8/10/12/14/16		50X32/3/4	180X100X10/12/14/16
45X45X3/4/5/6	140X140X10/12/14/16		56X36/3/4/5	180X110X10/12/14/16
50X50X3/4/5/6	150X150X8/10/12/14/15/16		63X40X4/5/6/7	200X125X12/14/16/18
56X56X3/4/5/6/7/8	160X160X10/12/14/16		70X45X4/5/6/7	/
60X60X5/6/7/8	180X180X12/14/16/18		75X50X5/6/8/10	/
63X63X4/5/6/7/8/9/10	200X200X14/16/18/20/24		80X50X5/6/7/8	/
70X70X4/5/6/7/8	220X220X16/18/20/22/24/26		90X56X5/6/7/8	/
75X75X5/6/7/8/9/10	250X250X18/20/24/26/28		100X63X6/7/8/10	/
